Home ProductsTorsion Spiral Spring

Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys

Certification
Good quality Flat Spiral Spring for sales
we cooperate with Norvee more than 10 years, we order the tobacco pusher springs and they can provide very good quality, in time delivery.

—— David Smith from Russia

Norvee can provide good quality gas spring, we order from them for many years and have very good cooperation.

—— William from Australia

we order the music material extension springs from Norvee since 2005, there is never quality problem and we order from them all the time till now.

—— Bill from USA

I'm Online Chat Now

Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys

China Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys supplier
Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys supplier Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys supplier

Large Image :  Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys

Product Details:

Place of Origin: CHINA
Brand Name: NV
Certification: ISO9001
Model Number: NV-0220

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Price: negotiation
Packaging Details: carton packing
Delivery Time: 10 to 14 work days
Payment Terms: L/C, , T/T, Western Union
Supply Ability: 2 000 000PCS/month
Contact Now
Detailed Product Description
Material: Stainless Steel Colour: White
Tolerance: 0.01mm Thickness: 0.08-1.8mm
Length: 100mm To 900mm Outside: As Your Drawing

stainless steel 301 flat Spiral spring cigarette pusher spring for vending machine



Springs'Specifications:





constant force spring, torque spring, power spring, constant force compression springs



1) motor brush

2) industrial tools

3) height adjustment

4) medical and healthcare device

5) roller shutter or window balance

6) store propelling shelf and POP display

7) automatically and transportation device



spiral spring, torsion spring



1) timers

2) cord retractors

3) counter balance

4) wind-up toys and games

5) electrical and mechanical reels



Material Stainless steel,carbon steel,62Si2Mn,60Si2Mn,65Mn,SK4,SK5
Load type Constant and variable force
Thickness of material 0.08mm~ 1.8mm
Wire diameter 0.01mm~ 10mm
Width 1mm~ 250mm
Inside diameter As your request
Outside diameter 1 mm and above.
Length of springs Free length as you need
Surface treatment Zinc plated, nickel plated, black coating,also can be done as customers request
Application Furniture,industrial equipment,electronic devices,etc
Equipments Advanced CNC computer spring machines with high precision and efficiency
Technology Experienced engineers ,technicians and Skilled Workers
Certification ISO9001:2008
Advantage High quality, competitive prices,automatic production equipment, , safe package and fast delivery



Our service:



1. Can design for you

2.  Advanced equipments of Springs

3. High quality with competitve price

4. Safe package

5. Fast delivery



Applications for power springs



· Tobacco shelf pusher

· seatbelt retractors

· tape measures

· retractable dog leads

· electrical cord retractors

· hose reels

· wind-up toys

· pull start on small gas-powered engines

· tool balancers

· valves

· computer monitor





Height Adjustment Stainless Steel Coil Springs Cigarette Pusher Spring For Toys



Motor spring



Motor spring for circular motion in max 10 and 20 coils, except pre-tension as specified below. The spring is usually positioned in a housing with the outer hook located around a pin or in a slot on the housing with the smallest internal diameter as specified below. It can also be placed in a larger housing, but with an associated decrease in force.



Clock spring



The clock spring (also referred to as a flat torsion spring) is designed to produce a torsional force (circular movement). In contrast to the tightly coiled motor spring on the previous page, the clock spring has open coils that, when mounted correctly, reduces fricton to zero. However, torque capacity is reduced as a result. The standard range is made from rounded edge stainless steel, which affords a better fatigue life.



Constant force spring



The constant force spring consists of strip material, which has been shaped and pre-tensioned into a tightly wound roll. The spring is used in a linear movement and produces almost constant force throughout its deflection. Constant force springs can be fitted in a number of ways and extended partly or completely. There is practically no limit on extension speed and acceleration.
